Zionpark ZY-YD03 Heavy-Duty Barrier Gate for Secure Access Control and Parking Management
The Nexpark ZY-YD03 is a high-performance automatic barrier gate engineered for seamless integration into modern parking management and access control systems. Built with durability and precision in mind, it delivers exceptional reliability for commercial, industrial, and residential applications. Its robust construction and advanced features ensure smooth operation even in high-traffic environments, making it the ideal choice for enhancing security and efficiency.
Robust 24V DC Motor
Equipped with a high-torque, low-noise motor for smooth and quiet lifting operations. The 24V DC design ensures safety, energy efficiency, and compatibility with standard power systems.
Durable Construction
Features a cold-rolled steel housing with anti-corrosion powder coating, providing weather resistance and long-term durability. The lightweight yet sturdy aluminum alloy boom is customized in length (3m/4m/6m) and coated with reflective sleeves for high visibility.
Intelligent Control System
Supports integration with loop detectors, photocells, and access control devices (e.g., RFID card readers, license plate recognition systems). Enables automated "raise-stop-lower" logic for collision prevention and seamless vehicle management.
Safety & Reliability
Includes built-in overload protection, a manual release mechanism for power outages, and obstacle detection support. Ensures operational safety for vehicles and pedestrians.
Easy Installation & Maintenance
Designed for straightforward deployment with standard mounting hardware. Minimal maintenance requirements due to its modular design and high-quality components.
Application scenarios
Product Parameters
|
ZY-YD03 DC Brushless Barrier |
|
|
Power Supply |
AC 220V ±10% 50/60Hz |
|
Motor |
100W DC Brushless |
|
Input Voltage |
24V DC |
|
Rated/Peak Current |
8A / 30A |
|
Arm Length |
Straight ≤6m / Articulated ≤4m |
|
Protection |
Overcurrent/Overvoltage/Short-circuit |
|
Input Signals |
Open/Close/Stop/Ground loop/Anti-collision |
|
Output Signals |
Dry contact (Open/Close status) |
Technical Specifications
● Boom Length: 3m / 4m / 6m (customizable)
● Lifting Time: 3-6 seconds (90° angle)
● Operating Temperature: -30°C to +75°C
● Control Interface: Dry contact (open/close/stop)
● Safety Features: Loop detector interface, photoelectric sensor support, mechanical clutch
